Floor & Wall Mounted Davit Sleeves & Sockets


3M/Sala Flush Core Mount Base High Capacity

Galvanised Steel Flush Core Mount Base High Capacity Stainless Steel Flush Core Mount Base High Capacity
Click on main image to expand

The Flush Core Mount Base High Capacity fixed base is the perfect solution for siting your davit socket if you have a suitable concrete base to mount it in. Please ensure that your concrete conforms to the strength requirements needed. Simply core drill the concrete and set the Core Mount in place using a suitable resin anchor. Because there is no up-stand they pose little risk as a trip hazard and insertion of the davit masts parts is easy.

As with all davit sleeves dirt and debris can build up in them over time and render them unusable, so you may also require a davit socket cover.

All davit sleeves require a visual inspection every 6 months with a detailed and thorough examination including a load test every 12 months.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Flush Core Mount Base High Capacity - Galvanised Steel £219.40
Flush Core Mount Base High Capacity - Stainless Steel £550.65
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Material Handling Capacity: 340kg
Dimensions: Depth: 235mm
Outer Diameter: ø 127mm
Inner Diameter: ø 103.3mm
Weight: Galvanised Steel Option: 5.40kg
Stainless Steel Option: 5.20kg
Mast Rotation: 360°
Standards: CE EN795:2012 Type A
EN1496:2006 Class B
CEN/TS16415:2013 Type B
Top

3M/Sala Floor Mount Base High Capacity

Galvanised Steel Floor Mount Base High Capacity Stainless Steel Floor Mount Base High Capacity
Click on main image to expand

The Floor Mount Base High Capacity fixed base is ideal if there is little room to site a davit or there are other items in close proximity as the mounting base is 30.48cm square.

Fitted using 4 studs if in concrete, or bolts if on steel or other suitable surfaces, the process is as simple as it gets. Please ensure that your concrete conforms to the strength requirements needed for this sleeves use.

The Floor Mount Base High Capacity does stand proud and may be a trip hazard and this should be considered when conducting your risk assessment.

As with all davit sleeves dirt and debris can build up in them over time and render them unusable, so you may also require a davit socket cover.

All davit sleeves require a visual inspection every 6 months with a detailed and thorough examination including a load test every 12 months.

We supply Anchor Fixing kits specific to these davits and these are shown below.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Floor Mount Base High Capacity - Galvanised Steel £396.40
Floor Mount Base High Capacity - Stainless Steel £744.85
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Material Handling Capacity: 340kg
Dimensions: 304.8mm x 304.8mm x 241.3mm
Davit Inner Diameter: ø 103.3mm
Weight: 15.60kg
Mast Rotation: 360°
Standards: CE EN795:2012 Type A
EN1496:2006 Class B
CEN/TS16415:2013 Type B
Top

3M/Sala Wall Mount Base High Capacity

Galvanised Steel Wall Mount Base High Capacity Stainless Steel Wall Mount Base High Capacity
Click on main image to expand

The Wall Mount Base High Capacity fixed base is perfect when the area to be accessed may only have a concrete up-stand or be on the internal or external wall of a tank or silo. It is fitted using either 4 studs if in concrete, or bolts if on steel or other suitable surfaces.

As with all davit sleeves dirt and debris can build up in them over time and render them unusable, so you may also require a davit socket cover.

All davit sleeves require a visual inspection every 6 months with a detailed and thorough examination including a load test every 12 months.

We supply Anchor Fixing kits specific to these davits and these are shown below.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Wall Mount Base High Capacity - Galvanised Steel £410.15
Wall Mount Base High Capacity - Stainless Steel £646.65
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Material Handling Capacity: 340kg
Dimensions: 232.9mm x 254.0mm x 190.5mm
Davit Inner Diameter: ø 103.3mm
Weight: 15.70kg
Mast Rotation: 360°
Standards: CE EN795:2012 Type A
EN1496:2006 Class B
CEN/TS16415:2013 Type B
Top

3M/Sala Flush Core Mount Base High Capacity

Galvanised Steel Flush Core Mount Base High Capacity Stainless Steel Flush Core Mount Base High Capacity
Click on main image to expand

The Flush Core Mount Base High Capacity fixed base offers the possibility of being used where the concrete is not of sufficient depth to take the Core Mount although it requires an amount of work to set it so that it can be used in a flush position. The easier way can be to core drill for the sleeve and then to resin anchor into place. The unit can also be used on other suitable surfaces as it can be bolted into place as the socket sleeve is designed to be able to cope with the loadings. As with all davit bases please ensure the surface being mounted to is able to take the loadings required.

As with all davit sleeves dirt and debris can build up in them over time and render them unusable, so you may also require a davit socket cover.

All davit sleeves require a visual inspection every 6 months with a detailed and thorough examination including a load test every 12 months.

We supply Anchor Fixing kits specific to these davits and these are shown below.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Flush Core Mount Base High Capacity - Galvanised Steel £626.00
Flush Core Mount Base High Capacity - Stainless Steel £1,288.65
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Material Handling Capacity: 340kg
Dimensions: 27.9cm x 29.9cm x 23.5cm
Weight: 12.40kg
Mast Rotation: 360°
Standards: CE EN795:2012 Type A
EN1496:2006 Class B
CEN/TS16415:2013 Type B
Top

3M/Sala Deck Mount Base High Capacity

Galvanised Steel Deck Mount Base High Capacity Stainless Steel Deck Mount Base High Capacity
Click on main image to expand

The Deck Mount Base High Capacity fixed base is a truly versatile way of placing a davit sleeve where you have a suitable surface such as steel. Simply drill the appropriate hole(s), insert the davit base and bolt the bottom mounting plate to the underside. The upper and lower flanges ensure that the sleeve will cope with the forces required. As with all davits bases please ensure that your design conforms to the loadings required of the base you are fitting.

As with all davit sleeves dirt and debris can build up in them over time and render them unusable, so you may also require a davit socket cover.

All davit sleeves require a visual examination every 6 months with a detailed and thorough examination including a load test every 12 months.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Deck Mount Base High Capacity - Galvanised Steel £665.95
Deck Mount Base High Capacity - Stainless Steel £1,248.70
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Capacity: Variable up to 450 lbs. (204 kg)
Dimensions: 8.10 x 8.10 x 10.00 (in)
Weight: 16.80 lbs (7.6kg)
Standards: CE EN 795 cl B
Top

3M/Sala Debris Cap for High Capacity Bases

Debris Protector for Sala High Capacity Davits
Click on main image to expand

Protect your davit sleeves from filling with detritus with a debris cap. The lifting eye sits within the unit to reduce any trip hazard.

Sales price excluding VAT
Debris Cap for High Capacity Bases £115.45
Top

ASH Sala Davit Debris Protector

ASH Sala Davit Debris Protector ASH Sala Davit Debris Protector in use
Click on main image to expand

The ASH Sala Davit Debris Protector is turned from nylon 66 to give a snug fit that to protect your davit sleeves from filling with detritus. It has a low profile domed top to reduce any trip hazard.

There is a M12 central thread for easy extraction from the davit sleeve.

Note: This unit is suitable for use with the Sala Advanced Range only.

Sales price excluding VAT
ASH Sala Davit Debris Protector £119.00
M12 Galvanized Eye Bolt £10.50
Top

Reid Top Mount Socket

Reid Top Mount Socket Reid Top Mount Socket
Click on main image to expand

The Reid Top Mount Socket is suitable for bolting into existing concrete, steel structures or through fixing in other substrates. They are secured using 4 x M16 anchors (not supplied). They are available for both the 65mm and 95mm kingpin diameter davits.

They are suitable for use with the full Reid davit range and certified to EN795:2021 and meet the requirements of IRATA ICOP. The galvanised steel top mount 65 meets the requirement of BS8610:2017.

When fixing sockets to structures, customers must always seek the guidance of a suitably qualified engineer to ensure that the structure is able to support the required loads.

All davit sleeves require a visual examination every 6 months with a detailed and thorough examination including a load test every 12 months.

We supply Anchor Fixing kits specific to these davits and these are shown below.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Top Mount Socket 65 GMS - diameter 65mm £223.35
Top Mount Socket 65 316SS - diameter 65mm £904.50
Top Mount Socket 95 GMS - diameter 95mm £289.63
Top Mount Socket 95 316SS - diameter 95mm P.O.A.
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Dimensions: Steel: 250mm x 250mm x 264mm
Aluminium: 300mm x 300mm x 265.35mm
Weight: Top Mount Socket 65 GMS: 13kg
Top Mount Socket 65 316SS: 17kg
Top Mount Socket 65 Aluminium Anodised: 9kg
Top Mount Socket 95 GMS: 29kg
Top Mount Socket 95 316SS: 30kg
Standards: EN795:2012
Meets the requirements of IRATA ICOP
Galvanised Steel Top Mount 65 meets the requirements of BS8610:2017
Top

Reid Side Mount Socket

Reid Top Mount Socket Reid Top Mount Socket
Click on main image to expand

The Reid Side Mount Socket is suitable for mounting on the side of concrete or steel structures and a brace plate can be supplied for thin-walled concrete. They are secured using M16 anchors (not supplied). They are available for both the 65mm and 95mm kingpin diameter davits.

They are suitable for use with the full Reid davit range and certified to EN795:2021 and meet the requirements of IRATA ICOP. The galvanised steel side mount 65 meets the requirement of BS8610:2017.

When fixing sockets to structures, customers must always seek the guidance of a suitably qualified engineer to ensure that the structure is able to support the required loads.

All davit sleeves require a visual examination every 6 months with a detailed and thorough examination including a load test every 12 months.

We supply Anchor Fixing kits specific to these davits and these are shown below.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Side Mount Socket 65 GMS - diameter 65mm £233.35
Side Mount Socket 65 316SS - diameter 65mm £800.19
Side Mount Socket 65 Aluminium Anodised - diameter 65mm £372.25
Side Mount Socket 95 GMS - diameter 95mm £296.84
Side Mount Socket 95 316SS - diameter 95mm P.O.A.
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Dimensions: Steel: 414mm x 222mm x 94.27mm
Aluminium: 414mm x 222mm x 197.27mm
Weight: Side Mount Socket 65 GMS: 13kg
Side Mount Socket 65 316SS: 17kg
Side Mount Socket 65 Aluminium Anodised: 6kg
Side Mount Socket 95 GMS: 30kg
Side Mount Socket 95 316SS: 29kg
Standards: EN795:2012
Meets the requirements of IRATA ICOP
Galvanised Steel Side Mount 65 meets the requirements of BS8610:2017
Top

Reid Bridge Mount Socket

Reid Bridge Mount Socket
Click on main image to expand

The Reid Bridge Mount Sockets are suitable for bolting into steel structures and designed to fit open mesh grating or set flush with structural steelwork. They are secured using M16 anchors (not supplied).

They are suitable only for use with Reid 65mm kingpin davits, certified to EN795:2021 and meet the requirements of IRATA ICOP.

When fixing sockets to structures, customers must always seek the guidance of a suitably qualified engineer to ensure that the structure is able to support the required loads.

All davit sleeves require a visual examination every 6 months with a detailed and thorough examination including a load test every 12 months.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Bridge Mount Socket 65 GMS £223.35
Bridge Mount Socket 65 316SS £923.68
Bridge Mount Socket 65 Aluminium Anodised £367.33
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Dimensions: 250mm x 250mm x 194mm
Weight: Bridge Mount Socket 65 GMS: 19kg
Bridge Mount Socket 65 316SS: 19kg
Bridge Mount Socket 65 Aluminium Anodised: 7kg
Standards: EN795:2012
Meets the requirements of IRATA ICOP
Top

Reid Flush Mount Socket

Reid Flush Mount Socket
Click on main image to expand

The Reid Flush Mount Sockets are suitable for either casting into concrete or resin fixing into existing concrete. They are available for both the 65mm and 95mm kingpin diameter davits.

They are suitable for use with the full Reid davit range, are certified to EN795:2021 and meet the requirements of IRATA ICOP.

When fixing sockets to structures, customers must always seek the guidance of a suitably qualified engineer to ensure that the structure is able to support the required loads.

All davit sleeves require a visual examination every 6 months with a detailed and thorough examination including a load test every 12 months.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Flush Mount Socket 65 GMS - diameter 65mm £134.02
Flush Mount Socket 65 316SS - diameter 65mm £645.09
Flush Mount Socket Resin Bond 65 GMS - diameter 65mm £134.02
Flush Mount Socket Resin Bond 65 316SS - diameter 65mm £604.11
Flush Mount Socket 95 GMS - diameter 95mm £454.64
Flush Mount Socket 95 316SS - diameter 95mm P.O.A.
Flush Mount Socket Resin Bond 95 GMS - diameter 95mm £185.88
Flush Mount Socket Resin Bond 95 316SS - diameter 95mm P.O.A.
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Dimensions: Depth: 252mm
Outer Diameter: ø 165mm
Weight: Flush Mount Socket 65 GMS: 5kg
Flush Mount Socket 65 316SS: 4kg
Flush Mount Socket Resin Bond 65 GMS: 5kg
Flush Mount Socket Resin Bond 65 316SS: 4kg
Flush Mount Socket 95 GMS: 9.5kg
Flush Mount Socket 95 316SS: 9.5kg
Flush Mount Socket Resin Bond 95 GMS: 9.5kg
Flush Mount Socket Resin Bond 95 316SS: 9.5kg
Standards: EN795:2012
Meets the requirements of IRATA ICOP
Top

Reid Socket Pedestals

Reid Socket Pedestals
Click on main image to expand

The Reid Socket Pedestals are only suitable for use with Reid 65mm kingping davits and are secured using M16 or M20 anchors (not supplied).

They are manufactured from lightweight aluminium and designed to provide additional lift height or reach over obstacles. They are certified for EN795:2012 up to a 1600mm radius and meet the requirements of IRATA ICOP up to a 1200mm radius. They are available in 3 standard height options; 500mm, 800mm and 1100mm.

When fixing sockets to structures, customers must always seek the guidance of a suitably qualified engineer to ensure that the structure is able to support the required loads.

All davit sleeves require a visual examination every 6 months with a detailed and thorough examination including a load test every 12 months.

We supply Anchor Fixing kits specific to these davits and these are shown below.

Please talk to us about ways we can reduce your future testing costs.

Sales price excluding VAT
Socket Pedestal 65 500mm £713.26
Socket Pedestal 65 800mm £734.24
Socket Pedestal 65 1100mm £755.22
Service price excluding parts and VAT
A detailed and thorough examination including a load test (per sleeve) £300.00
Day rate for the above (as many as we can get done for you) £750.00
Dimensions: Bottom Diameter: ø 370mm, Top Diameter: ø 152mm
Weight: Socket Pedestal 65 500mm: 17kg
Socket Pedestal 65 800mm: 19kg
Socket Pedestal 65 1100mm: 19kg
Standards: EN795:2012 up to 1600mm radius
Meets the requirements of IRATA ICOP up to 1200mm radius
Top

Reid Socket Extensions

Reid Socket Extensions
Click on main image to expand

The Reid Socket extensions are suitable for use with Reid 65mm kingping davits combined with 65mm fixed sockets to provide additional lift height or reach over obstacles. They are certified for EN795:2012 up to a 1600mm radius and meet the requirements of IRATA ICOP up to a 1200mm radius. They are available in 3 standard height options; 500mm, 800mm and 1100mm.

They are made from lightweight aluminium alloy with handles for lifting and carrying. Simple insert them into the existing socket and assemble a standard davit as normal using the extension as the socket.

Socket extensions must not be used with a pedestal.

Sales price excluding VAT
Socket Extension 500mm £631.12
Socket Extension 800mm £652.11
Socket Extension 1100mm £673.08
Service price excluding parts and VAT
Socket Extension £10.00
Weight: Socket Extension 500mm: 12kg
Socket Extension 800mm: 15kg
Socket Extension 1100mm: 17kg
Standards: EN795:2012 up to 1600mm radius
Meets the requirements of IRATA ICOP up to 1200mm radius
Top

Anchor Fixing Kits

16mm Resin Anchor Fixing Kit 12mm Resin Anchor Fixing Kit
Click on main image to expand

Our anchor fixing kits include resin, 2 nozzles, stainless nuts, bolts and washers for davit bases and height safety anchor points.

We also have the correct sizes of diamond core drill bits and SDS hammer drill bits available to suit the installation along with ETA resin that is tested for use with both diamond core or impact drill installation.

The fittings provided in our kits are stainless steel so they will conform to water industry standards. Once your installation has hardened it can then be tested using our STAHT Bluetooth tester to the manufacturers and standards requirements so that a certificate of conformity can be issued.

Cone widths do need to be understood and if you scan the QR Code on our kits it will take you to a video of how to do the install correctly and then you are also able to complete a Fischer online test to show that you fully understand how to conduct and test the install correctly.

Ash Safety are a fully authorised Fischer Distributor and can supply any of their fixings for other tasks along with a Fischer CDM check using their latest software to ensure that cone strengths will take the loadings that you may be creating during your lifting process or if a fall takes place onto your anchor point. Please contact us for more details.

Sales price excluding VAT
Kit 1 - M16 Davit Socket £38.39
Kit 2 - M12 Anchor Fixing £33.41
FIS AM Dispenser £22.37
DCB 14 Dimond Core Bit £51.38
DCB 18 Dimond Core Bit £53.90
SDS Hammer Drill Bit: Quattric II 14/210/260 £12.80
SDS Hammer Drill Bit: Quattric II 14/400/450 £17.92
SDS Hammer Drill Bit: Quattric II 14/160/210 £10.88
SDS Hammer Drill Bit: Quattric II 14/260/310 £14.40
SDS Hammer Drill Bit: Quattric II 18/200/250 £22.40
SDS Hammer Drill Bit: Quattric II 18/400/450 £31.76
Top

Related Items:
