Ladders & Ladder Systems

The Ash Ladder Set offers a simple solution to a third point of contact leaving both hands free to operate hand tools. The set adjusts simply and fits almost any make of ladder whilst being easy to use.

The ladder standoff accommodates for pipe work and corners of buildings allowing for three different positions. Stabilisers offer increased stability and the rope strop harness and connector come in a handy storage bag.

The set consists of: one twin point full body harness, 1 x 10 metre rope (ladders of 10.5m maximum) 1 x 1000kg 0.5 metre endless sling, 1 x rope rocker, 2 x screw gate karabiners, one transit bag, one pair of ladder stabilisers and one ladder standoff.

The KS 8000 is a rigid rail system that is designed to be fitted onto ladders to provide a fall arrest system that is easy to use.

The system attaches to the ladder rungs and the worker connects a traveller to their chest fall arrest harness position. The traveller then goes up and down the rail system with relative ease unless the wearer slips. If this happens the traveller will lock onto the rail and stop the wearer from falling.

The traveller has a built-in indicator that shows if the traveller has captured a fall at any time. The system rail has entry and exit points for the traveller and also has a 1.5m arc section that allows the wearer to access the top of the ladder and get onto a safe part of the platform before disconnecting.

This system has a safe working load limit of 100kg gross for the wearer and a specialist quote should be sought for using this type of system.

The system is rated EN 353-1:2014 and ATEX/EX.

The KS 9000 Ladder System is a vertical fall arrest system composed of ladder rungs fixed on an aluminium rail to provide access at height for areas which do not have existing ladders.

The system rail has entry and exit points for the traveller and also has a 1.5m arc section that allows the wearer to access the top of the ladder and get onto a safe part of the platform before disconnecting. The trolley and rail entry and exit points are equipped with a non-inverting system to avoid the trolley being installed upside down.

The worker connects a traveller to their chest fall arrest harness position. The traveller then goes up and down the rail system with relative ease unless the wearer slips. If this happens the traveller will lock onto the rail and stop the wearer from falling.

The traveller has a built-in indicator that shows if the traveller has captured a fall at any time.

This system has a safe working load limit of 100kg gross for the wearer and a specialist quote should be sought for using this type of system.

The system is rated EN 353-1:2014 and ATEX/EX.

The Cabloc vertical cable system is easy and quick to install on a variety of structures including ladders, monopoles, masts, pylons, wind turbines and lighting columns. The system can be installed on structures that incline up to 15 degrees.

The components are made from high-quality materials with corrosion-resistant finishes that can stand up to a wide range of aggressive environments. The 8mm cable used with the system is available in both galvanised and stainless steel and can be ordered in the length required for your installation. There is an optional ladder extension bracket that can be included to enable safer connection and disconnection at the top of the ladder.

The Cabloc traveller can be attached and detached at any point along the cable to allow for access to platforms and adjacent work areas. Once attached the traveller automatically follows the user and locks in the event of a fall. This allows the user uninterrupted movement during accent and decent whilst maintaining safety.

The traveller has an anti-inversion feature that prevents the user from mounting it on the cable incorrectly. An integrated energy absorber reduces the maximum fall arrest force and acts as a fall indicator.

The Cabloc system is CE marked and conforms to EN 353-1:2014. The traveller is suitable for a single user with a maximum weight of 140kg.

The system is available in kits that include all the components required or they can be purchased individually for a custom system.

The Lad-Saf flexible cable vertical safety system can be easily installed on structures such as fixed ladders, telecommunication towers and more to provide fall arrest when ascending and descending. The system can be set for 2 or 4 users and meets the requirements of EN353-1:2014.

The system can be used on a variety of fixed ladder styles that may consist of different rung spacings and shapes:

• Rung spacings: 200 - 310mm
• Cylindrical Rung: 19 - 40mm diameter
• Square Rung: 19 - 40mm
• Diamond Rung: 19 - 40mm height
• Angle Iron: 19 - 40mm leg height
• Rectangular Rung: 19 - 40mm height, 19 - 48mm width

The top connector for the system has an integrated fall arrest rated anchor point and a climb extension can be included to enable safer connection and disconnection at the top of the ladder.

The 9.5mm cable for the system comes pre-swaged at the desired length in either galvanised or stainless steel and is offered in the following increments:

• 5m to 10m in 1m increments
• 10m to 50m in 2m increments
• 50m to 100m in 5m increments

The Lad-Saf X3 detachable cable sleeve is a portable connection device that connects the worker's harness to the ladder cable. It glides freely up and down the cable without further handling. In the event of a fall the sleeve locks onto the cable and arrests the fall and will remain locked until the worker can regain their footing.

The system has two independent locking mechanisms and an integrated energy absorber to reduce the maximum fall arrest force. This absorber also acts as a fall indicator showing the device has been deployed and needs to be removed from service. The X3 detachable cable sleeve has a swivel end connector to provide the user with increased mobility while climbing. The cable sleeve is approved for use by 1 user with a maximum weight of 140kg.
